World-Leading Supplier of Nucleic Acid Synthesis Upstream Products
2 Years
| Ask Lasest Price | |
| Brand Name : | Honya Biotech |
| Model Number : | HY-12 |
12 Primers of 20bp within 2.5 hours Making Machine for Life Science DNA/RNA/Probes Synthesis
HY-12 OLIGO SYNTHESIZER
HY-12 Oligo Synthesizer is the best performing medium throughput oligo synthesizer on the market.
It can run with scales varing from 25nmol to 300umol, with a typical run time is less than 2.5 hours for 12 columns of DNA 20mers. It has been placed in many universities, pharmaceutical and diagnostic companies.
Picture Show:
Specifications:
Channel | 12 | Synthesis Type | DNA/RNA.fluorescent dyes/sulfurizing/Probe |
Mode | Reagent Injection Separately | Period(20 Mer) | 12 primers of 20bp within 2.5h |
Cycled Time | 4-6min | Synthesis Scale | 25nmol-300umol |
Coupling Rate | >99% | Max Length of Primer | 120bp |
Bearing Method | Synthetic column | Wastes | vacuum |
Base/Reagent Pouring Mode | reagent injection separately | Base/Reagent Drive Way | press out by protected gas |
Amidite Position Base | 16pcs | Reagent Position Base | 9 pcs |
Reagent Cylinder Configuration | single position standard. double optional | Reagent Bottle Size | 450ml/4L Customization |
Synthesis Merger Base | Automatic merge the base | Data Import Method | Import the sequence automatically by Excel |
Gas needed | Nitrogen or Argon | Color | Pure White |
Reagent Pipe Dimension | OD1/8' and ID/16' | Base Pipe Dimension | OD1/16, ID0.8mm |
Outsize | 1100*710*890mm | Package Size | 1200*810*1000mm |
Working Environment | 25℃±4℃ | Relative humidity | ≤45% |
Power | Single Phase/220V | Gas needed | Nitrogen or Argon |
Technical Advantages:
1 | lightweight and modular design | which is designed easy to add or removing modules. And optimize the configuration in future. |
2 | Compact design | which using an embedded control computer, no more space for computer, shortening half of the length than other similar synthesizer |
3 | Graphical operation mode | In the testing phase and the initial stage of synthesis, the pipeline can be tested automatically, the status of liquids, pipelines, valves, etc. |
4 | Larger synthesis scale | dual-axis motion system reduced the length of the column support plate ,also saves a lot of space to put larger scale columns. And it can synthesize 12 primers at the same time, which is twice as large as the traditional synthesizer |
5 | AMI/MODIFY can be flexibly configured | Base amidite and modified amidite can be set freely, and you can choose different Synthesis programme |
6 | OXI/SUL can be configured separately | OXI and SUL can be configured separately. |
7 | Independent programme of each channel | Each channel can select different sequence files and process parameters, which can set the initial synthesis position of the sequence and Initialization/finalization mode respectively, etc. For each channels programme can be saved, loaded, tested, and statistically analyzed. |
8 | Real-time display of the synthesis process | During the synthesis process, it can be paused manually or automatically, and then the operate the amidite and other reagent. |
|
|
